Inox Steel India is a trusted manufacturer, supplier, and global exporter of Titanium Tubes manufactured in accordance with ASTM B338, covering commercially pure titanium (Grade 2) and high-performance titanium alloys (Grade 5, Grade 9, Grade 12). We supply to industries across GCC, Middle East, Africa, Europe, USA, Canada, and South America, ensuring top-quality tubes with mill test certification, heat number traceability, and stringent metallurgical control.
Known for unmatched corrosion resistance, low density, excellent biocompatibility, and high strength-to-weight ratio, titanium tubes are the first choice for critical applications in chemical processing, marine engineering, heat exchangers, aerospace systems, automotive components, medical equipment, and nuclear sectors.
With ISO 9001, PED, IBR, and EN 10204 3.1/3.2 certifications, Inox Steel India ensures every titanium tube is manufactured under precise controlled conditions to deliver consistent quality and long-term reliability in demanding environments.
Titanium tubes are hollow cylindrical products made from high-purity or alloyed titanium, designed for environments requiring:
Titanium is more corrosion-resistant than stainless steel, lighter than steel or nickel alloys, and maintains strength even at elevated temperatures — making it indispensable in advanced engineering applications.
Inox Steel India produces Titanium Tubes using state-of-the-art equipment and controlled metallurgical practices.
ASTM B338 covers: Seamless titanium tubes, Welded titanium tubes, Annealed & cold-worked conditions, Heat exchanger, condenser & general corrosion-resistant services. Your master table provides detailed mechanical, chemical, and dimensional properties for Grades 2, 5, 9, and 12.
(Grades: Gr 2 · Gr 5 · Gr 9 · Gr 12)
| Parameter / Property | Titanium Grade 2 (Commercially Pure) | Titanium Grade 5 (Ti-6Al-4V) | Titanium Grade 9 (Ti-3Al-2.5V) | Titanium Grade 12 (Ti-0.3Mo-0.8Ni) |
| Material Type | Commercially Pure Titanium | Alpha-Beta Titanium Alloy | Alpha-Beta Titanium Alloy | Modified CP Titanium |
| Standard | ASTM B338 | ASTM B338 | ASTM B338 | ASTM B338 |
| UNS Number | R50400 | R56400 | R56320 | R53400 |
| Key Characteristics | High corrosion resistance, lightweight, excellent ductility | High strength, heat resistant, aerospace quality | High strength-to-weight, excellent cold formability | Superior corrosion resistance in reducing acids |
| Typical Applications | Heat exchangers, condensers, marine, chemical | Aerospace tubes, high-pressure systems, defence | Bicycle frames, sports equipment, medical | Chemical processing, chlor-alkali, brine plants |
| Temperature Range | −196 °C to 350 °C | Up to 400 °C | Up to 350 °C | Up to 425 °C |
| Corrosion Resistance | Excellent | Very Good | Excellent | Superior (acidic + reducing) |
| Tensile Strength (MPa) | 345 min | 895 min | 620 min | 483 min |
| Yield Strength (MPa) | 275 min | 828 min | 483 min | 345 min |
| Elongation (%) | 20% | 10% | 15% | 18% |
| Hardness | 80–90 HRB | 36 HRC max | 90 HRB | 82 HRB |
| Density (g/cm³) | 4.51 | 4.43 | 4.48 | 4.50 |
| Modulus of Elasticity (GPa) | 103 | 114 | 110 | 105 |
| Chemical Composition (%) | Ti ≥ 99.2% | Al 5.5–6.75%, V 3.5–4.5%, Ti balance | Al 2.5–3.5%, V 2.0–3.0%, Ti balance | Mo 0.3%, Ni 0.8%, Fe ≤0.3%, Ti balance |
| Manufacturing Method | Seamless / Welded | Seamless | Seamless / Welded | Seamless / Welded |
| Outside Diameter (OD) | 6 mm – 114 mm | 6 mm – 76 mm | 6 mm – 76 mm | 6 mm – 114 mm |
| Wall Thickness | 0.5 mm – 10 mm | 0.5 mm – 8 mm | 0.4 mm – 8 mm | 0.5 mm – 10 mm |
| Schedules Available | SCH 5 – SCH 80 | SCH 5 – SCH 80 | SCH 5 – SCH 80 | SCH 5 – SCH 80 |
| Length | 3M · 6M · 12M | 3M · 6M · 12M | 3M · 6M · 12M | 3M · 6M · 12M |
| End Finish | Plain / Bevelled | Plain / Bevelled | Plain / Bevelled | Plain / Bevelled |
| Surface Finish | Annealed, Pickled, Polished | Annealed | Annealed, Pickled | Annealed, Pickled |
| Hydrostatic Test | ✓ | ✓ | ✓ | ✓ |
| Eddy Current Test | ✓ | ✓ | ✓ | ✓ |
| Ultrasonic Test | ✓ | ✓ | ✓ | ✓ |
| PMI Test | ✓ | ✓ | ✓ | ✓ |
| Mechanical Tests | ✓ | ✓ | ✓ | ✓ |
| IGC / Corrosion Testing | ✓ | ✓ | ✓ | ✓ |
| Third-Party Inspection | SGS · BV · TUV · DNV | SGS · BV · TUV | SGS · BV | SGS · BV · TUV |
| Industry Use | Chemical · Marine · Heat Exchangers · Pharma | Aerospace · Defence · High Pressure | Sports · Medical · Automotive · Marine | Petrochemical · Chlor-alkali · Brine systems |
| Certifications | ISO 9001 · PED · EN 10204 3.1/3.2 | Same | Same | Same |
| HSN Code | 8108.20.10 | 8108.20.10 | 8108.20.10 | 8108.20.10 |
For high-pressure/structural applications → Grade 5, Grade 9. For corrosion-only environments → Grade 2, Grade 12.
Brine/chlorine → Grade 12. Seawater → Grade 2. Organic acids → Grade 2. High temperature + strength → Grade 5.
PED, IBR, EN 10204 3.1/3.2, NACE (where applicable).
Major consuming regions: Mumbai, Dahej, Hazira, Vizag, Chennai. Industries: Chemical plants, Heat exchanger units, Pharma & medical systems, Desalination and marine.
High-volume usage for: Chlor-alkali systems, Offshore oil platforms, Desalination units, Heat exchangers.
Demand driven by: Aerospace and defence, High-purity chemical systems, Medical implants/devices, Power and heat exchanger manufacturing.
Used for: Mining chemical plants, Water treatment, Fertilizer and acid processing units.
Titanium tubes are the preferred choice for environments requiring high corrosion resistance, lightweight construction, superior metallurgical stability, and long-term performance under thermal cycling. Grades 2, 5, 9, and 12 each offer distinct mechanical and chemical benefits, making them suitable for industrial, aerospace, marine, power generation, and medical sectors.
🔹 Titanium Grade 2 Tubes
🔹 Titanium Grade 5 Tubes
🔹 Titanium Grade 9 Tubes
🔹 Titanium Grade 12 Tubes
| NPS (Inch) | OD (mm) | Wall Thickness (mm) | Approx. Weight (kg/m) |
| ½″ | 12.7 | 0.9 | 0.25 |
| ¾″ | 19.05 | 1.2 | 0.48 |
| 1″ | 25.4 | 1.5 | 0.78 |
| 2″ | 50.8 | 2.0 | 2.90 |
| 4″ | 101.6 | 3.0 | 10.50 |
Full dimensional chart (SCH 5 – SCH 80) available on request.
| Grade | OD Range | Price INR/kg (F.O.B Mumbai) | USD/kg (F.O.B India) | Typical Applications |
| Grade 2 | 6–114 mm | ₹ 1,450 – 2,050 | $18 – $25 | Heat exchangers, condensers |
| Grade 5 | 6–76 mm | ₹ 2,900 – 4,000 | $35 – $48 | Aerospace, medical, high-pressure |
| Grade 9 | 6–76 mm | ₹ 2,200 – 3,200 | $27 – $38 | Sports, thin-wall tubing |
| Grade 12 | 6–114 mm | ₹ 1,850 – 2,600 | $23 – $32 | Chlor-alkali & acid plants |
Prices vary based on OD, WT, annealed condition, origin (USA, Japan, Europe) & TPI requirements.
We follow ASTM B338 requirements combined with enhanced metallurgical testing protocols.
Mechanical Testing
Non-Destructive Testing
Chemical & Metallurgical
Documentation Provided: EN 10204 3.1 / 3.2, PED Compliance, Heat Treatment Chart, MTC, IBR Certification (if applicable), Third-Party Inspection (SGS, BV, TÜV, DNV).
Heat TreatmentSolution annealed, Stress relieved, Controlled atmosphere annealing (for aerospace grades).
Dimensional ToleranceASTM B338 OD / WT tolerances. TEMA tolerances for heat exchanger tubing.
End FinishingPE (Plain End), BE (Bevelled End), Custom machining available.
Inox Steel India is widely recognized as a reliable Titanium Tube Supplier near Alankar Cinema, Mumbai, supplying ASTM B338 Grade 2, Grade 5, Grade 9, and Grade 12 titanium tubes across India and more than 40+ countries. Our strong inventory, global certifications, and expert metallurgical support make us the preferred supplier for chemical plants, power plants, desalination facilities, aerospace manufacturers, medical equipment makers, and engineering companies.
| Industry | Applications | Prefered Titanium Grade |
| Chemical Processing | Acid loops · Chlorine systems · Heat exchangers | Grade 2 / Grade 12 |
| Power & Energy | Condensers · Cooling towers · Boiler tubes | Grade 2 / Grade 12 |
| Pharmaceutical & Biotech | Ultra-clean tubing · Sterile systems | Grade 2 / Grade 9 |
| Aerospace & Defence | Hydraulic lines · Aircraft tubes · Structural assemblies | Grade 5 |
| Marine & Offshore | Seawater cooling · Marine piping | Grade 2 |
| Desalination Plants | Brine circulation · Evaporators | Grade 2 / Grade 12 |
| Sports Equipment | Bicycle frames · High-performance tubing | Grade 9 |
| Automotive & EV Industry | Lightweight tubing · Heat exchangers | Grade 9 |
We follow premium export-grade packing to ensure the tubes reach safely across continents.
Packaging Includes
Marking Includes
Export Ports: JNPT – Mumbai | Mundra – Gujarat | Hazira – Gujarat. Our logistics team ensures timely delivery to all major global destinations.
Whether you need titanium tubes for a chemical plant in India, a desalination project in the Middle East, or a medical or aerospace application in Europe or the USA — our experts are equipped to recommend the ideal grade and supply at competitive pricing.
52-A, Mulji Thackersi Bldg, Islampura Street, Shop No. 10, Near Alankar Cinema, Mumbai – 400 004
steel@inoxsteelindia.in
+91 9930796690
B338 covers seamless & welded tubes; B862 covers welded titanium tubes only. Titanium is immune to seawater corrosion and has a very long service life. Grade 2 is the most widely used for heat exchangers and condensers. Yes—BV, DNV, TUV available. What is the difference between ASTM B338 and B862?
Why use titanium for condensers?
Which titanium grade is most commonly used?
Do you provide third-party inspection?
Inox Steel India offers premium-quality, mill-tested, globally certified Titanium Tubes engineered for the toughest applications. From commercial-grade titanium to aerospace alloys, we support projects across chemical, marine, defence, power, and medical sectors.
