Titanium Hex Bars Manufacturer, Supplier & Exporter – Inox Steel India
Grades: Titanium Grade 2 (CP Ti), Titanium Grade 5 (Ti-6Al-4V)
Inox Steel India is a manufacturer, supplier, and exporter of titanium hex bars, supplying to aerospace, defence, chemical processing, marine, and high-performance engineering industries across India, the Middle East, Europe, Africa, and the Americas.
Titanium hex bars are supplied in Grade 2 (commercially pure titanium) and Grade 5 (Ti-6Al-4V alloy), manufactured in accordance with ASTM B348 / ASME SB348 standards. These grades are selected for applications requiring exceptional strength-to-weight ratio, corrosion resistance, and long-term reliability under demanding service conditions.
With controlled processing, certified heat treatment, and dimensional accuracy, titanium hex bars supplied by Inox Steel India offer consistent mechanical properties, excellent surface integrity, and suitability for critical structural and fastening applications.
Titanium hex bars are solid long products with a hexagonal (six-sided) cross section, manufactured from titanium and titanium alloys known for being lightweight yet exceptionally strong. The hexagonal profile allows positive tool grip and torque transfer, making these bars suitable for bolts, fasteners, fittings, and precision-machined components.
Titanium hex bars are produced from titanium billets using hot rolling, forging, or cold drawing, followed by annealing or solution treatment (for Grade 5) to achieve the required strength, ductility, and microstructural stability.
Manufacturing Steps:
1️⃣ Billet Selection & Heating
Titanium billets of Grade 2 or Grade 5 are selected and heated under controlled atmospheres.
2️⃣ Hot Rolling / Forging
Billets are rolled or forged through hexagonal passes to obtain accurate across-flat dimensions.
3️⃣ Cold Drawing (Where Required)
Bars may be cold drawn to improve surface finish and dimensional tolerance.
4️⃣ Heat Treatment
Grade 2 is supplied annealed; Grade 5 may be supplied annealed or solution treated & aged as required.
5️⃣ Straightening & Cutting
Bars are straightened and cut to standard or custom lengths.
6️⃣ Final Inspection
Chemical analysis, mechanical testing, and dimensional inspection are performed prior to dispatch.
These characteristics make titanium hex bars ideal for high-performance and safety-critical components.
🧩 Grades & Standards Available
Titanium hex bars are supplied in the following grades:
Materials are supplied as per ASTM B348 / ASME SB348 specifications.
MASTER TECHNICAL DATA SHEET:
Titanium Hex Bars
| Parameter | Titanium Grade 2 (CP Ti – UNS R50400) | Titanium Grade 5 (Ti-6Al-4V – UNS R56400) |
|---|---|---|
| Product Form | Hexagonal Bars (Solid) | Hexagonal Bars (Solid) |
| Standard | ASTM B348 / ASME SB348 | ASTM B348 / ASME SB348 |
| Material Type | Commercially Pure Titanium | Alpha-Beta Titanium Alloy |
| Manufacturing Process | Hot Rolled / Forged / Bright (Cold Drawn) | Hot Rolled / Forged / Bright (Cold Drawn) |
| Surface Finish | Mill / Bright / Polished | Mill / Bright / Polished |
| Supply Condition | Annealed | Annealed / Solution Treated & Aged (as required) |
| Titanium (Ti) % | Balance | Balance |
| Aluminum (Al) % | — | 5.5 – 6.75 |
| Vanadium (V) % | — | 3.5 – 4.5 |
| Oxygen (O) % | ≤0.25 | ≤0.20 |
| Iron (Fe) % | ≤0.30 | ≤0.40 |
| Tensile Strength (MPa) | ≥345 | ≥895 |
| Yield Strength (MPa) | ≥275 | ≥828 |
| Elongation (%) | ≥20 | ≥10 |
| Hardness | ~150 – 200 HB | ~300 – 360 HB |
| Density | ~4.51 g/cm³ | ~4.43 g/cm³ |
| Corrosion Resistance | Excellent | Very Good |
| Strength-to-Weight Ratio | High | Very High |
| Machinability | Moderate | Moderate |
| Weldability | Excellent | Good |
| Standard AF Sizes (mm) | 8 – 60 | 8 – 60 |
| Approx. Weight @12 mm AF | 0.98 kg/m | 0.98 kg/m |
| Approx. Weight @20 mm AF | 2.72 kg/m | 2.72 kg/m |
| Approx. Weight @30 mm AF | 6.11 kg/m | 6.11 kg/m |
| Standard Length | 3 m / 6 m | 3 m / 6 m |
| Custom Cut Length | Available | Available |
| Dimensional Tolerance | As per ASTM B348 | As per ASTM B348 |
| Testing | Chemical, Mechanical | Chemical, Mechanical |
| Certification | EN 10204 3.1 / 3.2 | EN 10204 3.1 / 3.2 |
| HSN / HS Code | 8108 | 8108 |
| Typical Applications | Chemical, Marine, Heat Exchangers | Aerospace, Defence, Fasteners |
| Packaging | Bundled / Wooden Crates | Bundled / Wooden Crates |
When selecting titanium hex bars, the following parameters should be evaluated:
1️⃣ Strength vs Weight Requirement
2️⃣ Corrosion Environment
3️⃣ Operating Temperature
4️⃣ Fastening or Structural Use
5️⃣ Compliance with Aerospace / Defence Standards
Correct grade selection ensures performance reliability and service longevity.
🌍 Usage & Demand Overview
In India, titanium hex bars are widely used by aerospace suppliers, defence contractors, chemical processing plants, and marine equipment manufacturers, particularly for applications where weight reduction and corrosion resistance are critical.
Export demand is driven by aerospace, medical, offshore, and high-end engineering projects requiring ASTM-compliant titanium materials.
Titanium hex bars supplied by Inox Steel India are selected for applications where high strength-to-weight ratio, corrosion resistance, and long-term reliability are critical. Grade selection depends on mechanical load, operating environment, and weight sensitivity.
🧩 Applications by Grade / Type
Titanium Grade 2 (Commercially Pure) Hex Bars
Service Use: Corrosive and chemically aggressive environments with moderate strength requirements.
Typical Applications: Chemical processing equipment, heat exchangers, marine fittings, condenser components.
Industry Sectors: Chemical | Marine | Power | Process Industries
Titanium Grade 5 (Ti-6Al-4V) Hex Bars
Service Use: High-strength and weight-critical applications.
Typical Applications: Aerospace fasteners, defence components, high-performance bolts, structural fittings.
Industry Sectors: Aerospace | Defence | Offshore | Advanced Engineering
Titanium hex bars are supplied in standard metric hex bar sizes as per ASTM tolerances.
(Refer to standard hex bar sizes in mm PDF and hex bar size chart in mm India for detailed dimensions and weights.)
⚖ Titanium Hex Bar Weight Chart (Indicative)
| AF Size (mm) | Approx. Weight (kg/m) |
|---|---|
| 8 | 0.43 |
| 10 | 0.68 |
| 12 | 0.98 |
| 16 | 1.74 |
| 20 | 2.72 |
| 25 | 4.25 |
| 30 | 6.11 |
| 40 | 10.86 |
| 50 | 16.90 |
| 60 | 24.60 |
Weights are indicative and may vary slightly due to tolerance and alloy composition.
💰 Titanium Hex Bars Price (Indicative – India)
| Grade | Approx. Price Range (INR / kg) |
|---|---|
| Titanium Grade 2 | ₹ 1,200 – ₹ 2,200 |
| Titanium Grade 5 | ₹ 2,800 – ₹ 4,800 |
Prices vary based on size, heat-treatment condition, finish, quantity, and global titanium raw material rates.
HSN Code: 8108
Applicable for titanium and titanium alloy bars and rods under Indian and international trade classification.
🧪 Testing & Quality Inspection
Titanium hex bars are inspected and tested to ensure compliance with applicable standards.
Testing includes:
Material can be supplied with EN 10204 3.1 / 3.2 certification on request.
Inox Steel India supplies titanium hex bars with controlled metallurgy, certified processing, and full traceability for high-performance and weight-critical applications. Material is processed and inspected to meet stringent industry and project requirements.
Key supply features:
🧩 Industries Served
Titanium hex bars are supplied to the following industries:
Grade selection is aligned with load conditions, corrosion exposure, and weight optimization requirements.
📦 Packaging & Supply
Titanium hex bars are packed and dispatched as per standard industrial and export practices to prevent contamination and surface damage.
Dispatch supported through JNPT (Mumbai), Mundra, and Hazira ports for export shipments.
Standard across-flat sizes range from 8 mm to 60 mm. Other sizes can be supplied on request. Yes. Titanium offers excellent corrosion resistance in marine, chemical, and aggressive environments. The applicable HSN code is 8108. Yes, custom cut lengths are available as per requirement. Material can be supplied with EN 10204 3.1 / 3.2 test certification on request. What are the standard hex bar sizes in mm?
Are titanium hex bars corrosion resistant?
What is the HSN code for titanium hex bars?
Are custom cut lengths available?
Is test certification provided with supply?
