Titanium is one of the most advanced engineering materials used today — a metal that combines extreme corrosion resistance, exceptional strength-to-weight ratio, biocompatibility, seawater stability, and high-temperature performance.
INOX STEEL INDIA supplies Titanium Welded Tubes in Grade 2 (Commercially Pure) and Grade 5 (Ti-6Al-4V) for demanding industries such as desalination, aerospace, power generation, offshore, chemical processing, heat exchangers, and medical systems.
Our welded tubes are manufactured to ASTM B338 / B862, using high-purity shielding gas, controlled welding parameters, and oxygen-free weld environments to achieve flawless weld integrity.
Titanium tubes are produced by rolling titanium strip/plate and welding it using:
Titanium forms a self-healing oxide layer, making it one of the most corrosion-resistant materials on earth.
Key Characteristics
🔹 Titanium Grade 2 — Commercially Pure (CP Titanium)Best for:
Best for:
Why Grade 2?
Perfect for industries requiring:
🔹 Titanium Grade 5 — Ti-6Al-4V (High-Strength Alloy)
Best for:
Why Grade 5?
Grades: Grade 2 (Commercially Pure) • Grade 5 (Ti-6Al-4V)
Standards: ASTM B338 / ASTM B862
Category: Titanium Welded Tubes
Brand: INOX STEEL INDIA
| Section | Parameter | Technical Specification — Titanium Welded Tubes |
|---|---|---|
| General | Product | Titanium Welded Tubes |
| Grades | Gr 2 (CP Titanium) • Gr 5 (Ti-6Al-4V) | |
| Standards | ASTM B338 (Seamless & Welded Titanium Tubes) • ASTM B862 (Welded Titanium Tubing) | |
| Manufacturing | TIG / Plasma welded from CP Titanium or Ti-6Al-4V strip • Annealed & pickled | |
| Material Characteristics | Grade 2 (CP) | High corrosion resistance, excellent ductility, low density, ideal for heat exchangers & chemical processing |
| Grade 5 (Ti-6Al-4V) | High strength, lightweight, heat-resistant alloy used in aerospace, power & offshore | |
| Chemical Composition (%) | Gr 2 | Ti ≥ 98.9%, O ≤ 0.25%, Fe ≤ 0.30%, (N, C, H) trace |
| Gr 5 | Ti bal., Al 5.5–6.75%, V 3.5–4.5%, (O, Fe) trace | |
| Mechanical Properties | Gr 2 | YS 275 MPa, TS 345 MPa, Elongation ≥ 20% |
| Gr 5 | YS 880–950 MPa, TS 950–1100 MPa, Elongation 10–14% | |
| Physical Properties | Density | 4.5 g/cm³ (45% lighter than steel) |
| Melting Point | ~1660°C | |
| Thermal Conductivity | Low (better stability in heat-exchanger systems) | |
| Corrosion Resistance | Chlorides | Excellent (Gr 2) |
| Seawater | Excellent (CP Titanium) | |
| High-Temperature Oxidation | Excellent (Gr 5) | |
| Acids | Resistant to HNO3, mildly reducing acids, seawater | |
| Dimensional Range | Outside Diameter | 6 mm – 168 mm |
| Wall Thickness | 0.5 mm – 6.0 mm | |
| Lengths | 1–12 meters | |
| Shapes | Round (standard), square/rectangular limited | |
| Welding Characteristics | Weld Methods | TIG / Plasma / Laser welding |
| Filler Metals | Grade 2 → ERTi-2 • Grade 5 → ERTi-5 | |
| Requirements | High-purity argon shielding, oxygen control, color-free weld | |
| Heat Treatment | CP Titanium | Annealed |
| Grade 5 | Stress-relieving or annealing (application-based) | |
| Testing | Mandatory | Hydrostatic, Eddy Current, Mechanical |
| Optional | RT, UT, PT, Microstructure, Oxygen analysis | |
| PMI | Required for aerospace & critical service | |
| Surface Finish | Types | Bright annealed • Pickled • Polished |
| End Conditions | Pipe Ends | Plain Ends (PE), Deburred |
| Advantages of Titanium Tubes | Key Benefits | Lightweight, corrosion-proof, non-toxic, seawater-resistant, long life cycle |
| Applications | Heat Exchangers | Desalination, condensers, power plants |
| Offshore & Marine | Seawater cooling & riser systems | |
| Chemical Industry | Chloride-heavy systems | |
| Aerospace | Lightweight structural & hydraulic systems | |
| Medical | Clean, biocompatible applications | |
| HSN Code | 8108 (Titanium & Titanium Alloy Tubes) |
Heat Exchangers & Desalination
Offshore & Marine
Aerospace & Chemical
| Property | Grade 2 | Grade 5 (Ti-6Al-4V) |
|---|---|---|
| Strength | Medium | Very High |
| Weight | Very light | Very light |
| Weldability | Excellent | Medium (requires expertise) |
| Heat Resistance | High | Excellent |
| Cost | Lower | Higher |
| Application | Heat exchangers, seawater | Aerospace, offshore, power |
| Outside Diameter (OD) | Wall Thickness (WT) | Application |
|---|---|---|
| 6 – 12.7 mm | 0.5 – 1.0 mm | Instrumentation, laboratory tubing |
| 12.7 – 25.4 mm | 0.7 – 1.5 mm | Heat exchangers, condensers |
| 25.4 – 50.8 mm | 1.0 – 2.5 mm | Marine cooling, desalination |
| 50.8 – 114 mm | 1.2 – 4.0 mm | Chemical processing, reactors |
| 114 – 168 mm | 1.5 – 6.0 mm | Offshore, power plant piping |
| 168 – 219 mm | 2.0 – 6.0 mm | Aerospace structures & heavy-duty systems |
Standard Lengths: 3m • 6m • 12m | Custom Cut Length: Available for heat exchanger bundles.
| Alloy | Max Continuous Temperature | Ideal for |
|---|---|---|
| Titanium Grade 2 | ~300°C | Heat exchangers, seawater, chemical plants |
| Titanium Grade 5 (Ti-6Al-4V) | ~400–600°C | Aerospace, offshore, high-pressure & thermal systems |
Grade 5 retains excellent mechanical strength at elevated temperatures compared to Grade 2.
| Corrosive Media | Grade 2 | Grade 5 | Comments |
|---|---|---|---|
| Seawater | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | Titanium is immune to seawater attack |
| Chlorides | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | Both grades stable due to protective oxide layer |
| Oxidizing Acids | ⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | Grade 5 more stable at elevated temperature |
| Reducing Acids | ⭐⭐⭐ | ⭐⭐⭐ | Titanium requires controlled environments |
| High-Temperature Oxidation | ⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | Grade 5 preferred |
Titanium requires controlled, oxygen-free welding. Colored welds indicate contamination.
Welding Processes Used
| Titanium Grade | Filler Metal | AWS Code | Notes |
|---|---|---|---|
| Grade 2 | ERTi-2 | AWS A5.16 | Matches CP Titanium chemistry |
| Grade 5 (Ti-6Al-4V) | ERTi-5 | AWS A5.16 | Essential for strength retention |
Welding Requirements
| Property | Titanium Grade 2 | Stainless Steel (316L) | Cu-Ni 90/10 |
|---|---|---|---|
| Density | 4.5 g/cm³ (light) | 8.0 g/cm³ | 8.9 g/cm³ |
| Seawater Corrosion | ⭐⭐⭐⭐⭐ | ⭐⭐ | ⭐⭐⭐⭐ |
| Heat Exchanger Use | ⭐⭐⭐⭐⭐ | ⭐⭐⭐ | ⭐⭐⭐⭐ |
| Thermal Conductivity | Low | Medium | High |
| Strength | Medium | Medium | Low |
| Life Expectancy | 30–50 years | 10–20 years | 20–25 years |
Conclusion:
Titanium = best for aggressive seawater + lifetime performance
SS = cost-efficient but poor in chlorides
Cu-Ni = excellent marine + good heat transfer
Mandatory Tests (ASTM B338 / B862)
Optional Tests (For EPC / Aerospace / Nuclear)
Documentation Provided
( price depends on grade, OD, WT, weld type & origin.)
| Grade | Welded Tube Price (INR/Kg) | Price (USD/Kg) |
|---|---|---|
| Titanium Grade 2 | ₹ 2,500 – ₹ 3,800 | $30 – $45 |
| Titanium Grade 5 | ₹ 4,200 – ₹ 6,500 | $50 – $78 |
| Finish | Applications |
|---|---|
| Bright Annealed | Aerospace, medical |
| Pickled & Passivated | Heat exchanger & chemical units |
| Polished | Architectural or hygiene-based systems |
| Cleaned & Degreased | Semiconductor, oxygen service |
✔ 1. Expertise in Titanium Welding (TIG / Plasma / Laser)
Titanium welds must be silver, contamination-free, and performed under strict oxygen control (<50 ppm O₂).
At INOX:
This ensures leak-proof, corrosion-stable welds.
✔ 2. Strict Conformance to ASTM B338 / ASTM B862
Every Titanium Grade 2 & Grade 5 tube is supplied with:
✔ 3. Titanium for Lifetime Seawater & High-Temp Performance
Why industries choose Titanium tubes:
✔ 4. Export-Ready Supplier for EPC / OEM / Desalination Plants
Regular supply to projects in:
UAE • Saudi Arabia • Oman • Qatar • Singapore • South Korea • Europe • USA • Africa
We support EPC contractors with:
✔ 5. Wide Range — OD 6 mm to 168 mm
We supply welded titanium tubes for:
Pan-India Supply: Mumbai • Pune • Chennai • Hyderabad • Bengaluru • Ahmedabad • Delhi NCR.
Global Export Hubs: Dubai • Doha • Muscat • Riyadh • Jeddah • Abu Dhabi • Singapore • Rotterdam.
Titanium Grade 2 is the global standard for:
Grade 5 tubing is used for:
Titanium withstands chlorides & oxidizers.
Used in:
Corrosion-free performance in subsea conditions.
Biocompatible & non-toxic.
Standard Packaging
Export Packaging
Documentation✔ MTC (EN 10204 3.1/3.2)
✔ Weld maps
✔ PMI reports
✔ NDT/DT test records
✔ TPI approvals (if required)
