Home > Square Bar > Titanium Square Bars
Grades: Titanium Grade 2 & Titanium Grade 5 (Ti-6Al-4V)
Inox Steel India is a trusted manufacturer, supplier, stockist, and exporter of titanium square bars, offering premium-quality Titanium Grade 2 and Titanium Grade 5 (Ti-6Al-4V) square bars for applications that demand exceptional strength-to-weight ratio, corrosion resistance, and long service life. Titanium square bars are widely used in aerospace, defence, chemical processing, marine engineering, medical devices, and high-performance industrial systems.
Titanium stands apart from steel and nickel alloys due to its light weight combined with very high mechanical strength and outstanding resistance to corrosion in aggressive environments such as seawater, chlorides, and chemical media. For this reason, titanium square bars are often selected where weight reduction, durability, and reliability are critical design requirements.
All titanium square bars supplied by Inox Steel India conform to ASTM B348, ASTM F67, and ASTM F136 standards, ensuring consistent metallurgy, traceability, and compliance with global project and medical specifications.
A titanium square bar is a solid square-section bar manufactured from commercially pure titanium or titanium alloys. These bars are designed to deliver high strength at significantly lower weight compared to steel, while maintaining excellent corrosion resistance and biocompatibility.
Titanium square bars are preferred when:
The square geometry provides flat reference surfaces and torsional stability, making titanium square bars suitable for precision machining, structural components, and load-bearing assemblies.
Inox Steel India follows controlled processing methods to ensure titanium square bars meet demanding engineering and medical requirements.
Manufacturing Process Overview:
This process ensures consistent strength, corrosion resistance, and dimensional accuracy across all supplied bars.
Titanium square bars offer unique advantages over carbon steel, stainless steel, and nickel alloys:
These benefits make titanium square bars ideal for high-performance and safety-critical components.
Inox Steel India supplies titanium square bars in two widely used grades:
🔹 Titanium Grade 2 Square Bars
Commercially pure titanium offering excellent corrosion resistance, good strength, and superior weldability. Commonly used in chemical processing, marine applications, heat exchangers, and medical equipment.
🔹 Titanium Grade 5 (Ti-6Al-4V) Square Bars
Titanium alloy with aluminium and vanadium, providing exceptional strength, fatigue resistance, and high-temperature performance. Widely used in aerospace, defence, medical implants, and high-stress engineering components.
MASTER TECHNICAL DATASHEET – TITANIUM SQUARE BARS
| Parameter | Titanium Grade 2 | Titanium Grade 5 (Ti-6Al-4V) |
|---|---|---|
| Material Category | Commercially Pure Titanium | Alpha-Beta Titanium Alloy |
| UNS Number | R50400 | R56400 |
| ASTM Specification | ASTM B348 / F67 | ASTM B348 / F136 |
| Alloy Composition | ≥ 99.2% Ti | Ti-6% Al-4% V |
| Density | 4.51 g/cm³ | 4.43 g/cm³ |
| Tensile Strength | ≥ 345 MPa | ≥ 895 MPa |
| Yield Strength | ≥ 275 MPa | ≥ 828 MPa |
| Elongation | ≥ 20 % | ≥ 10 % |
| Hardness | ≤ 160 HB | ≤ 349 HB |
| Strength-to-Weight Ratio | Very High | Exceptional |
| Corrosion Resistance | Excellent | Excellent |
| Temperature Resistance | Up to 400°C | Up to 600°C |
| Weldability | Excellent | Good |
| Machinability | Fair | Fair |
| Magnetic Property | Non-Magnetic | Non-Magnetic |
| Heat Treatment | Annealed | Annealed / Solution Treated |
| Surface Finish | Mill / Ground | Mill / Ground |
| Manufacturing Process | Forged / Rolled | Forged / Rolled |
| Size Range (Square) | 6 mm – 100 mm | 6 mm – 100 mm |
| Length | Random / Fixed / Cut Length | Random / Fixed / Cut Length |
| Testing | Chemical, Mechanical, PMI | Chemical, Mechanical, PMI |
| Certification | EN 10204 3.1 / 3.2 | EN 10204 3.1 / 3.2 |
| Biocompatibility | Excellent | Excellent |
| HSN / HS Code | 8108.90.00 | 8108.90.00 |
| Typical Applications | Chemical, Marine, Medical | Aerospace, Defence, Medical |
Before selecting titanium square bars, engineers and buyers should consider:
Correct grade selection ensures optimal performance, weight efficiency, and lifecycle cost control.
This section provides engineering-grade and procurement-ready clarity for Titanium Grade 2 and Grade 5 square bars, covering standard sizes, weight calculation, indicative pricing in India, testing requirements, and real-world application mapping.
Inox Steel India supplies titanium square bars in standard market sizes as well as custom cut lengths for aerospace, chemical, marine, and medical applications.
Standard Square Bar Sizes (mm)
6 | 8 | 10 | 12 | 16 | 20 | 22 | 25 | 30 | 32 | 35 | 40 | 45 | 50 | 60 | 65 | 70 | 75 | 80 | 100
Length: Random (3–6 m) or fixed / cut lengths
Tolerance: As per ASTM B348
Finish: Mill finish, Ground / Machined (on request)
Commonly requested sizes include 12mm, 20mm, 25mm, 40mm, and 50mm titanium square bars for precision machining and structural use.
The following square bar weight chart helps in BOQ preparation and price estimation.
(Density considered: Grade 2 ≈ 4.51 g/cm³, Grade 5 ≈ 4.43 g/cm³)
| Square Size (mm) | Grade 2 (kg/m) | Grade 5 (kg/m) |
|---|---|---|
| 10 × 10 | 0.45 | 0.44 |
| 12 × 12 | 0.65 | 0.64 |
| 16 × 16 | 1.15 | 1.13 |
| 20 × 20 | 1.80 | 1.77 |
| 25 × 25 | 2.82 | 2.77 |
| 30 × 30 | 4.06 | 3.99 |
| 40 × 40 | 7.22 | 7.09 |
| 50 × 50 | 11.28 | 11.09 |
| 65 × 65 | 19.07 | 18.71 |
| 75 × 75 | 25.37 | 24.89 |
| 100 × 100 | 45.10 | 44.30 |
Addresses buyer searches such as:
steel square bar weight vs titanium
titanium square bar weight per meter
titanium bar stock calculation
Titanium pricing depends on grade, size, finish, certification, and quantity. Below is an indicative titanium bar price per kg for reference.
Indicative Price Range (INR/kg – India)
| Grade | Approx. Price / Kg (INR) | Typical Use |
|---|---|---|
| Titanium Grade 2 | ₹ 2,200 – ₹ 3,200 | Chemical, marine, heat exchangers |
| Titanium Grade 5 (Ti-6Al-4V) | ₹ 4,200 – ₹ 6,500 | Aerospace, defence, medical |
Prices fluctuate based on sponge cost, import duties, certification (medical/aerospace), and order volume.
HSN Code (India): 8108.90.00
HS Code (Export): 8108.90
Applicable to titanium bars and rods, for domestic billing and international export documentation.
All titanium square bars supplied by Inox Steel India undergo strict testing to ensure suitability for critical applications.
Titanium square bars are selected where weight reduction, corrosion resistance, and long-term reliability are essential.
Engineers, OEMs, and global buyers choose Inox Steel India for technical confidence, documentation strength, and supply reliability.
Key Advantages:
Our objective is to deliver high-purity titanium with consistent mechanical performance and traceability.
| Industry | Application | Preferred Grade |
|---|---|---|
| Aerospace | Structural parts, fasteners | Grade 5 |
| Defence | Lightweight, high-strength components | Grade 5 |
| Chemical Processing | Reactors, heat exchangers | Grade 2 |
| Marine & Offshore | Corrosion-resistant hardware | Grade 2 |
| Medical & Healthcare | Implants, surgical instruments | Grade 5 |
| Power & Energy | High-performance components | Grade 5 |
Titanium square bars are packed to protect surface integrity and dimensional accuracy.
Packing Standards:
Export Markets: UAE, Saudi Arabia, Europe, Africa, Southeast Asia
Domestic Supply: Mumbai, Ahmedabad, Pune, Chennai, Bengaluru
Whether you need Grade 2 titanium for corrosion-resistant applications or Grade 5 titanium for aerospace and defence, Inox Steel India delivers certified quality, competitive pricing, and reliable global supply.
52-A, Mulji Thackersi Bldg, Islampura Street, Shop No. 10, Near Alankar Cinema, Mumbai – 400 004
alloy@inoxsteelindia.in
+91 9930796690
Grade 2 is commercially pure with excellent corrosion resistance, while Grade 5 is a titanium alloy with much higher strength.
Yes, titanium offers exceptional resistance to seawater corrosion.
Yes, we supply titanium as per ASTM F67 and ASTM F136 standards on request.
Standard sizes range from 6 mm to 100 mm, with custom cut lengths available.
Inox Steel India supplies titanium square bars in Grade 2 & Grade 5. Get latest price per kg, sizes, weight chart & certified stock in India.
