Condenser Tubes – ASTM B111 / B338 Manufacturer in India

Inox Steel India – Seamless & Welded Condenser Tubes for Power Plants, Refineries & Industrial Cooling Systems

Inox Steel India is a leading manufacturer, stockholder, and exporter of Condenser Tubes manufactured in accordance with ASTM B111 (Copper Alloy Tubes) and ASTM B338 (Titanium Tubes). These condenser tubes are engineered for high thermal conductivity, corrosion resistance, erosion resistance, and long lifecycle in cooling water, seawater, brine, and industrial fluid transfer systems.

We supply condenser tubes for:

  • Thermal power plant condensers
  • Desalination plant condensers
  • Refinery & petrochemical surface condensers
  • Marine coolers
  • HVAC & refrigeration systems
  • District cooling plants
  • Industrial process chillers

Condenser tubes play a critical role in transferring heat from steam to the cooling water circuit. Their performance directly affects turbine efficiency, energy output, and operational cost. Hence, tube material selection — Copper Alloys (ASTM B111) or Titanium (ASTM B338) — is essential depending on water quality, temperature, scaling tendency, and chloride levels.

Table of Contents

Understanding Condenser Tube Standards

🔹 ASTM B111 – Copper & Copper-Nickel AlloyASTM B111 covers seamless copper-nickel and copper alloy tubes with excellent thermal conductivity and seawater resistance.

Common grades:

  • C70600 (90/10 Cu-Ni) – Best for seawater
  • C71500 (70/30 Cu-Ni) – Higher strength, high chloride service
  • Admiralty Brass (C44300) – High thermal conductivity
  • Aluminium Brass (C68700) – High erosion resistance

🔹 ASTM B338 – Titanium Condenser TubesASTM B338 covers seamless and welded titanium tubes used in harsh seawater, brine, and corrosive environments.

Common grades:

  • Titanium Grade 2 – Excellent seawater resistance
  • Titanium Grade 5 – High strength
  • Titanium Grade 9 / Grade 12 – Enhanced corrosion resistance

Manufacturing Process of Condenser Tubes

Manufacturing Steps:

  1. Piercing & Hollow Formation: Seamless tubes are hot-extruded to ensure tube integrity.
  2. Cold Drawing / Cold Rolling: Refines wall thickness, OD, and internal surface smoothness.
  3. Straightening & Heat Treatment: Annealing, Stress relieving, and Bright annealing for titanium.
  4. Surface Cleaning: Decontamination essential for heat-transfer efficiency.
  5. NDT Testing: Eddy current, ultrasonic, hydrotest, air-under-water test.
  6. Finishing: Straight lengths, U-bent form, or Cut-to-length.

Why Industries Prefer ASTM B111 & B338 Tubes

  • High Thermal Conductivity: Copper alloys deliver superior heat-transfer efficiency.
  • Superior Corrosion Resistance: Titanium offers unmatched resistance to chlorides, brine & seawater.
  • High Erosion & Cavitation Resistance: Perfect for high-flow condenser applications.
  • Long Service Life: Titanium tubes last 20–40 years even in aggressive water.
  • Low Fouling Surface: Reduces scaling, enhancing overall plant efficiency.
  • Global Preference: Preferred by EPC contractors & OEMs for Power Plants + Desalination.

Applications & Technical Specifications of Condenser Tubes

Condenser Tubes are critical components in cooling systems where steam or hot process fluid must be condensed using seawater, brine, river water, or cooling tower water. They operate in environments involving high fluid velocity, continuous water contact, and biofouling risk.

Applications by Standard / Grade / Service Condition

🔹 ASTM B111 (Copper & Copper-Nickel)

  • Best for: High-conductivity, moderate corrosion, seawater service.
  • Grades: C70600 (Marine condensers), C71500 (Offshore), C44300 (Power), C68700 (High-velocity).
  • Industries: Marine · Desalination · Refinery · Fertilizer.
🔹 ASTM B338 (Titanium Condenser Tubes)

  • Best for: Highly corrosive water, high-flow systems, long-life condensers.
  • Grades: Grade 2 (Power plants), Grade 5 (Offshore), Grade 9 (Desalination), Grade 12 (Chemical).
  • Service Life: 20–40+ years in chloride-rich waters.

Dimensional Range (General)

  • Outside Diameter (OD): 9.52 mm – 50.80 mm
  • Wall Thickness (WT): 0.5 mm – 3 mm
  • Length: 6M · 12M · U-Bent · Custom
  • Finish: Plain · Bright Annealed · Polished · Pickled
  • Ends: Plain / Bevelled / U-Bent

Indicative Price Range — 2025 (INR + USD)

Standard Material Price (INR/kg) Price (USD/kg) Typical Use
ASTM B111 Copper Alloys ₹ 850 – ₹ 1,350 $11 – $17 Power Condensers
ASTM B111 90/10 & 70/30 Cu-Ni ₹ 950 – ₹ 1,850 $12 – $24 Seawater Cooling
ASTM B338 Titanium Grade 2 ₹ 1,850 – ₹ 3,200 $22 – $39 Coastal/Nuclear Condensers
ASTM B338 Titanium Grade 5 / 9 / 12 ₹ 2,200 – ₹ 3,800 $27 – $45 Offshore & Desalination HE

Prices vary depending on OD, WT, U-bending, export packaging, and TPI requirement.

Testing & Quality Assurance

Mechanical Tests

  • Tensile test
  • Hardness test
  • Elongation test
Non-Destructive Tests

  • Eddy current (EC) test
  • Hydrostatic test
  • Ultrasonic (UT) test
  • Air-under-water test
Corrosion & Material

  • PMI test
  • Salt-spray resistance
  • Copper-sulfate test
  • IGC test
Dimensional Checks

  • OD/WT tolerance
  • Straightness check
  • Ovality measurement
  • U-bend radius inspection

Certifications: EN 10204 3.1 / 3.2, ISO 9001, PED (on request). TPI Available: TUV, SGS, BV, DNV, Intertek.

Engineering Notes (For Condenser Designers)

  • Material Selection: Use ASTM B111 for high thermal conductivity and low-to-medium chlorides. Use Titanium (ASTM B338) for high chlorides (> 500 ppm), marine/offshore, and zero corrosion tolerance.
  • Velocity: Copper alloys are best at moderate flow; Titanium withstands higher velocity with excellent erosion resistance.
  • Tube Expansion: Titanium requires controlled torque expansion; Cu-Ni expands easily but needs careful pressure control.
  • Efficiency vs. Corrosion: Copper = best heat transfer; Titanium = best corrosion resistance. Select based on water quality.

Condenser Tube Supplier Near Alankar Cinema, Mumbai — Inox Steel India

Inox Steel India is a trusted manufacturer and stockist of Condenser Tubes near Alankar Cinema, Mumbai, supplying Copper Alloy (ASTM B111) and Titanium (ASTM B338) condenser tubes to power plants, refineries, desalination units, HVAC manufacturers, and industrial cooling system integrators.

Our tubes are designed for: Maximum heat-transfer efficiency, Long service life (20–40+ years for titanium), Superior seawater & brine corrosion resistance, Reliability in 24×7 thermal cycling, and High fluid velocity erosion resistance. We specialize in straight tubes, U-bent tubes, and custom-length condenser tubes, all tested, certified, and export-ready. Our high-integrity tubes are used by leading EPC contractors and OEMs for cooling water circuits in thermal, nuclear, chemical, marine, and process industries.

Why Choose Inox Steel India for Condenser Tubes?

  1. Full Range Under One Roof: ASTM B111 Copper Alloys (C44300, C68700, C70600, C71500) and ASTM B338 Titanium Grades (Gr 2, 5, 9, 12).
  2.  Industry-Required Properties: High thermal conductivity, superior seawater corrosion resistance, erosion & cavitation resistance, and excellent formability.
  3. U-Bent Condenser Tubes: Zero wall thinning, zero flattening, heat-treatment after bending, and precision radius control.
  4. Export-Ready Manufacturing: We export to UAE, Saudi Arabia, Qatar, Oman, South Africa, Egypt, Kenya, Germany, Spain, Italy, Poland, USA, Canada, Mexico, Brazil.
  5. Complete Project Documentation: EN 10204 3.1 / 3.2 MTC, NDT reports (EC, UT, HT), PMI reports, and heat treatment data.

Industries & Applications Served

Industry Applications
Thermal Power Plants Steam condensers · Cooling water exchangers
Nuclear Power Plants High-purity titanium condensers
Refineries & Petrochemical Surface condensers · Process coolers
Desalination Plants Brine heaters · Evaporator coils
Marine & Offshore Seawater cooling condensers
HVAC & District Cooling Large chillers · Cooling tower coils
Process Industries Oil cooling · Refrigerant condensers

Packaging & Export Handling

Every tube is packed to prevent corrosion, mechanical damage, and contamination.

Packaging Includes

  • Individual plastic end caps and HDPE wrapping.
  • Anti-corrosion oiling (for copper alloy tubes).
  • Wooden crates for U-bent tubes.
  • Marking: Grade · Standard · OD × WT · Heat Number.

Shipping Information

  • Ports: JNPT Mumbai | Mundra Port | Hazira Port.
  • Handling: FCL / LCL, Air shipments, Project cargo.



Quick Technical & Commercial Quote

For Copper Alloy and Titanium Condenser Tubes — straight or U-bent — our technical sales team is available to support your project.

Inox Steel India

52-A, Mulji Thackersi Bldg, Islampura Street, Shop No. 10, Near Alankar Cinema, Mumbai – 400 004

Email

alloy@inoxsteelindia.in, steel@inoxsteelindia.in

Phone

+91 9930796690

Frequently Asked Questions (FAQs)

Titanium (ASTM B338) → ultimate seawater resistance and long lifecycle
C70600 (90/10 Cu-Ni) → economical alternative for moderate seawater

Yes — with stress-relief heat treatment after bending and precise radius control.

Yes — Titanium offers superior chloride, brine, and biofouling resistance compared to any copper alloy.

20–40+ years depending on water quality.

Yes — we supply to GCC, Europe, Africa, USA, South America, and Southeast Asia.

Inox Steel India supplies seamless condenser tubes as per ASTM B111 (Copper, Cu-Ni) and ASTM B338 (Titanium). Ideal for power plants, desalination, refineries, marine cooling & HVAC systems. Exporter to GCC, Europe, Africa & USA.
