Inox Steel India is a manufacturer, supplier, and exporter of forged hex bars, supplying to heavy engineering, power, oil & gas, and industrial manufacturing sectors across India, GCC countries, the Middle East, Africa, Europe, and the Americas.
Forged hex bars are produced through open-die or closed-die forging, a process that refines the grain structure and enhances mechanical strength compared to rolled products. This makes forged hex bars suitable for high-load, high-stress, and safety-critical applications.
Inox Steel India supplies forged hex bars across carbon steel, alloy steel, stainless steel, duplex, tool steel, nickel alloys, titanium, and copper alloy grades, manufactured in compliance with applicable ASTM, ASME, EN, DIN, and IS standards.
Forged hex bars are solid hexagonal bars produced by deforming heated billets under compressive forces. Unlike rolling, forging aligns the internal grain flow with the shape of the component, resulting in superior mechanical properties and internal soundness.
Forged hex bars are typically supplied with forging tolerance and machining allowance, making them ideal for components that will undergo further machining.
These characteristics make forged hex bars ideal for load-bearing and safety-critical components.
Forged hex bars can be supplied in a wide range of materials, including:
Material selection depends on mechanical strength, service environment, and design requirements.
MASTER TECHNICAL DATA SHEET:
Forged Hex Bars
| Parameter | Forged Hex Bars |
|---|---|
| Product Form | Hexagonal Bars (Solid) |
| Manufacturing Process | Open Die Forging / Closed Die Forging |
| Applicable Materials | Carbon Steel, Alloy Steel, Stainless Steel, Duplex, Tool Steel, Nickel Alloy, Titanium, Copper Alloys |
| Standards (Material Dependent) | ASTM / ASME / EN / DIN / IS |
| Surface Finish | Forged Black / Rough Machined (Optional) |
| Edge Condition | Forged Profile (Rounded / Defined as per forging die) |
| Supply Condition | As Forged / Normalized / Annealed / Q&T / Solution Annealed (Material Dependent) |
| Heat Treatment Options | Normalized / Annealed / Q&T / Solution Annealed |
| Grain Structure | Refined & Directional (Improved Mechanical Strength) |
| Internal Soundness | Excellent (Low Porosity) |
| Dimensional Accuracy | Forging Tolerance (Machining Allowance Required) |
| Straightness | As per Forging Standard |
| Across Flats (AF) Size Range | 16 mm – 150 mm (Material & Process Dependent) |
| Larger Sizes | Available on Request |
| Standard Lengths | Random / Cut-to-Length |
| Custom Cut Lengths | Available |
| Machining Allowance | Required |
| Machinability | Good (After Heat Treatment) |
| Weldability | Material Dependent |
| Corrosion Resistance | Material Dependent |
| Typical Weight Basis | Calculated on AF dimension |
| Testing | Chemical, Mechanical, UT (On Request) |
| Certification | EN 10204 3.1 / 3.2 (on request) |
| HSN / HS Code | As per Base Material |
| Typical Applications | Heavy Duty Components, Shafts, Fasteners |
| Packaging | Bundled / Wooden Crates |
| Supply Mode | Domestic & Export |
When selecting forged hex bars, the following parameters should be evaluated:
Correct selection ensures structural integrity and long service life.
In India, forged hex bars are widely used by heavy engineering manufacturers, power equipment suppliers, oil & gas fabricators, and large machining units, especially in industrial hubs such as Pune, Chennai, Hyderabad, and Ahmedabad.
Export demand is driven by energy, offshore, and heavy machinery projects requiring forged components with certified quality.
Forged hex bars supplied by Inox Steel India are selected for applications requiring high load-bearing capacity, impact resistance, and internal soundness. Forging refines grain flow, making these bars suitable for critical and heavy-duty components where rolled products may not meet design margins.
Forged hex bars are supplied with forging tolerances and machining allowance, suitable for downstream machining.
(Refer to standard hex bar sizes in mm PDF and hex bar size chart in mm India for nominal dimensions; forged bars require machining allowance.)
Weights are calculated on nominal AF size and may vary due to forging allowance and material grade.
| AF Size (mm) | Indicative Weight (kg/m)* |
|---|---|
| 20 | 2.72 |
| 30 | 6.11 |
| 40 | 10.86 |
| 60 | 24.60 |
| 80 | ~43.70 |
| 100 | ~68.20 |
*Indicative only; actual weights depend on forging allowance and density of base material.
| Material Category | Approx. Price Range (INR / kg) |
|---|---|
| Carbon / Alloy Steel | ₹ 120 – ₹ 280 |
| Stainless / Duplex | ₹ 280 – ₹ 650 |
| Special Alloys | On Request |
Prices depend on material grade, section size, forging route, heat treatment, and quantity.
HSN Code: As per base material
(Commonly 7228 / 7222 / 7218 depending on alloy category)
Forged hex bars are inspected to ensure internal soundness and mechanical integrity.
Material can be supplied with EN 10204 3.1 / 3.2 certification on request.
Inox Steel India supplies forged hex bars with controlled forging practices, refined grain structure, and certified heat treatment to meet the demands of heavy-duty and safety-critical applications. Products are manufactured and inspected to ensure strength, reliability, and internal soundness.
Key supply features:
Forged hex bars are supplied to the following industries:
Material selection and forging route are aligned with load conditions, service environment, and project specifications.
Forged hex bars are packed and dispatched to protect material integrity during transit.
Dispatch supported through JNPT (Mumbai), Mundra, and Hazira ports for export shipments.
Forged Hex Bars Manufacturer & Supplier | Inox Steel India
52-A, Mulji Thackersi Bldg, Islampura Street, Shop No. 10, Near Alankar Cinema, Mumbai – 400 004
alloy@inoxsteelindia.in, steel@inoxsteelindia.in
+91 9930796690
Across-flat sizes typically range from 16 mm to 150 mm, with larger sizes available on request. Yes, forged hex bars are supplied with machining allowance for final component sizing. Yes, forged hex bars can be supplied in custom cut lengths as per requirement. Material can be supplied with EN 10204 3.1 / 3.2 test certification on request. What sizes are available in forged hex bars?
Are forged hex bars supplied with machining allowance?
Are custom cut lengths available?
Is test certification provided with supply?
Manufacturer and supplier of forged hex bars in carbon steel, alloy steel, stainless steel, and special alloys. Supplied with certified heat treatment by Inox Steel India.
